5.5-100HP Permanent magnet variable frequency screw air compressor

KAPA Intelligent Screw Air Compressor Series - 8~30Bar Full Pressure Section Solution

In the era of Industry 4.0, the intelligence and customization of compressed air systems have become the new industry standard. With 20 years of screw compression technology accumulation, KAPA Machinery has launched a series of intelligent screw air compressors covering pressures of 8~30Bar, with modular design to meet the differentiated needs of different industrial scenarios.

Inquire Now Next Product

Product Details

Technical Parmeters

Catalogue Download

1. Product core value matrix

Full pressure segment coverage technology

Low pressure segment (8-12Bar): standard model, suitable for general manufacturing industry

Medium pressure segment (13-20Bar): enhanced main engine, meeting special processes

High pressure segment (21-30Bar): military-grade design, breaking the industry limit

5.5-100HP Permanent magnet variable frequency screw air compressor

Dual-mode drive system

Variable frequency intelligent model:

Adopting permanent magnet synchronous motor, IE5 energy efficiency standard

0.1Bar level pressure precision control

5.5-100HP Permanent magnet variable frequency screw air compressor

Industrial frequency economic model:

Heavy-duty design, maintenance cost reduced by 40%

Support plateau type (altitude 5000 meters) customization

5.5-100HP Permanent magnet variable frequency screw air compressor

Service commitment

✓ 48-hour emergency response mechanism

✓ Lifetime warranty for pressure system

✓ Free energy efficiency evaluation service

✓ Spare parts delivered worldwide within 72 hours

Kapa 8-30Bar intelligent screw air compressor series redefines the industrial gas source standard with flexible pressure configuration. We sincerely invite partners from all industries to visit the experience center to obtain exclusive pressure solutions.

Model	Nominal Power		Working Pressure		Free Air Delivery		Weight（KG）	Noise Level	Dimensions (LxWxH)			Outlet size
60Hz	KW	HP	bar	psi	m3/min	cfm	KG	db(A)	（mm）
KQ4-8	4	5.5	8	116	0.61	21.54	181	65	750	750	800	RP1/2
KQ4-10	4	5.5	10	145	0.51	18.01	181	65	750	750	800	RP1/2
KQ5.5-8	5.5	7.5	8	116	0.80	28.25	181	65	750	750	800	RP1/2
KQ5.5-10	5.5	7.5	10	145	0.69	24.37	181	65	750	750	800	RP1/2
KQ5.5-13	5.5	7.5	13	189	0.60	21.19	181	65	750	750	800	RP1/2
KQ7.5-8	7.5	10	8	116	1.06	37.43	241	68	950	650	880	RP1/2
KQ7.5-10	7.5	10	10	145	0.96	33.90	241	68	950	650	880	RP1/2
KQ7.5-13	7.5	10	13	189	0.74	26.13	241	68	950	650	880	RP1/2
KQ11-8	11	15	8	116	1.87	66.04	330	68	1130	750	980	RP3/4
KQ11-10	11	15	10	145	1.85	65.33	330	68	1130	750	980	RP3/4
KQ11-13	11	15	13	189	0.97	34.26	330	68	1130	750	980	RP3/4
KQ15-8	15	20	8	116	2.27	80.16	385	68	1130	750	980	RP3/4
KQ15-10	15	20	10	145	2.21	78.05	385	68	1130	750	980	RP3/4
KQ15-13	15	20	13	189	1.82	64.27	370	68	1130	750	980	RP3/4
KQ18.5-8	18.5	25	8	116	2.83	99.94	469	70	1350	850	1140	RP1
KQ18.5-10	18.5	25	10	145	2.80	98.88	469	70	1350	850	1140	RP1
KQ18.5-13	18.5	25	13	189	2.18	76.99	455	70	1350	850	1140	RP1
KQ18.5-25	18.5	25	25	363	1.30	45.91	440	72	1350	850	1140	RP3/4
KQ18.5-30	18.5	25	30	435	1.20	42.38	440	72	1350	850	1140	RP3/4
KQ22-8	22	30	8	116	3.48	122.90	493	70	1350	850	1140	RP1
KQ22-10	22	30	10	145	3.45	121.84	493	70	1350	850	1140	RP1
KQ22-13	22	30	13	189	2.76	97.47	480	70	1350	850	1140	RP1
KQ22-25	22	30	25	363	1.70	60.03	470	70	1350	850	1140	RP3/4
KQ22-30	22	30	30	435	1.60	56.50	470	70	1350	850	1140	RP3/4
KQ30-8	30	40	8	116	4.21	148.67	531	72	1350	850	1140	RP1
KQ30-10	30	40	10	145	4.17	147.26	531	72	1350	850	1140	RP1
KQ30-13	30	40	13	189	3.39	119.72	515	72	1350	850	1140	RP1
KQ30-25	30	40	25	363	2.30	81.22	510	72	1350	850	1140	RP3/4
KQ30-30	30	40	30	435	2.10	74.16	510	72	1350	850	1140	RP3/4
KQ37-8	37	50	8	116	5.85	206.59	683	72	1480	1000	1200	RP1-1/2
KQ37-10	37	50	10	145	5.80	204.83	683	72	1480	1000	1200	RP1-1/2
KQ37-13	37	50	13	189	4.11	145.14	668	72	1480	1000	1200	RP1-1/2
KQ37-25	37	50	25	363	3.20	113.01	675	74	1480	1000	1200	RP3/4
KQ37-30	37	50	30	435	3.00	105.94	675	74	1480	1000	1200	RP3/4
KQ45-8	45	60	8	116	7.65	270.16	802	74	1480	1000	1270	RP1-1/2
KQ45-10	45	60	10	145	7.37	260.27	802	74	1480	1000	1270	RP1-1/2
KQ45-13	45	60	13	189	5.71	201.65	785	74	1480	1000	1270	RP1-1/2
KQ45-25	45	60	25	363	3.7	130.66	750	74	1480	1000	1270	RP1
KQ45-30	45	60	30	435	3.5	123.6	750	74	1480	1000	1270	RP1
KQ55-8	55	75	8	116	8.78	310.06	1120	74	1700	1250	1600	RP2
KQ55-10	55	75	10	145	8.64	305.12	1120	74	1700	1250	1600	RP2
KQ55-13	55	75	13	189	7.5	264.86	1120	74	1700	1250	1600	RP2
KQ55-25	55	75	25	363	4.2	148.32	880	78	1480	1000	1270	RP1
KQ55-30	55	75	30	435	4.0	141.26	880	78	1480	1000	1270	RP1
KQ75-8	75	100	8	116	11.31	399.41	1210	80	1700	1250	1600	RP2
KQ75-10	75	100	10	145	11.13	393.05	1210	80	1700	1250	1600	RP2
KQ75-13	75	100	13	189	8.83	311.83	1210	80	1700	1250	1600	RP2
KQ75-25	75	100	25	363	5.05	178.34	920	78	1480	1000	1270	RP1
KQ75-30	75	100	30	435	4.30	151.85	920	78	1480	1000	1270	RP1

AIR COMPRESSOR MAINTENANCE

The air compressor shouldbe placed in a place withclean air and good ventilation.

The air compressor should be placedhorizontally, with the belt side facingthe wall, and the maintenancespaceshould be reserved.

Before repairing and disassemblingthe air compressor, please tum offthe power supply and dischargethe air in the air seam.

When wiring, check whether thefan rotation direction is consistentwith the arrow direction.

ENERGY SAVING THCHNOLOGY

Power saving of 17000o kWh per month

The starting power of the original system is 555kw,and the starting power of the new system is 320kw.

Power saving of 17000o kWh per month

Power saving of 54000 kWh per month

The starting power of the original system is 240kW,and the starting power of the new system is 132kw.

Power saving of 54000 kWh per month

Power saving of 86000 kWh per month

The starting power of the original system is 446kW,and the starting power of the new system is 325kW.

Power saving of 86000 kWh per month

Power saving of 260000 kWh per month

The starting power of the original system is 690kw,and the starting power of the new system is 420kw.

Power saving of 260000 kWh per month

Power saving of 167000 kWh per month

The starting power of the original system is 732kW,and the starting power of the new system is 50okw.

Power saving of 167000 kWh per month

Power saving of 79000 kWh per month

The starting power of the original system is 430kw,and the starting power of the new system is 320kw.

Power saving of 79000 kWh per month
