Oil-free Screw Blower

Oil-free screw blower

Oil-free blower is widely used in: sewage treatment, aquaculture industry, textile bomb, aeration field and other low-pressure application fields quiet, efficient, 0.8-30bar.

Product Details
Technical Parmeters
Catalogue Download

Oil-free blower is widely used in: sewage treatment, aquaculture industry, textile bomb, aeration field and other low-pressure application fields quiet, efficient, 0.8-30bar.


01- Oil-free

To achieve lubrication, cooling, sealing, noise reduction of the four major effects, to provide high-quality 100% oil-free air, no pollution, no special treatment of discharged water, in line with environmental requirements;


02- Meet environmental requirements

Equipped with intake and exhaust noise reduction structure, the whole machine noise is lower;


03- Displacement

The exhaust volume is measured under the rated exhaust pressure. The recommended frequency of the frequency conversion series is 40%-100% or more. The model is 380v, and the standard power grid is used.


04- Other advantages

Efficient mainframe; Low noise to 73-85dB(A); Advanced starting device; Special check valve, the machine can be connected to the grid at any time to save 35-50% energy than Roots blower.


Oil-free screw blower


Advantages of Kapa Brand


1. High quality control(ISO 9001-2000/ISO14001/ASME/Energy saving certificate)

2. Fast Delivery( 10-15 days for large orders)

3. Good service for pre-sale,after-sale( strong technical support and professional after-sales team)

4. Small order acceptable( Ordering quantity according to your actual needs)


Why Choose Us?


Longer service life of the master machine

The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.


Permanent alignment of the electromotor and the master machine

Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.


Oil-free screw blower


ModelNominal
Power
Working
Pressure
Free Air
Delivery
Outlet
size
50HZ-60HZKW HPbarpsim3/mincfm
CAB11-15 VSD11151.521.753105DN190
CAB15-15 VSD15201.521.754.6162DN190
CAB22-15 VSD22301.521.756.3222DN190
CAB37-15 VSD37501.521.7512.2430DN190
CAB45-15 VSD45601.521.7517.1603DN190
CAB55-15 VSD55751.521.7522.6798DN190
CAB55-15 VSD55751.521.7526.3928DN250
CAB75-15 VSD751001.521.7534.11204DN250
CAB90-15 VSD901201.521.7543.81546DN250


AIR COMPRESSOR MAINTENANCE

01

The air compressor shouldbe placed in a place withclean air and good ventilation.

The air compressor shouldbe placed in a place withclean air and good ventilation.

02

The air compressor should be placedhorizontally, with the belt side facingthe wall, and the maintenancespaceshould be reserved.

The air compressor should be placedhorizontally, with the belt side facingthe wall, and the maintenancespaceshould be reserved.

03

Before repairing and disassemblingthe air compressor, please tum offthe power supply and dischargethe air in the air seam.

Before repairing and disassemblingthe air compressor, please tum offthe power supply and dischargethe air in the air seam.

04

When wiring, check whether thefan rotation direction is consistentwith the arrow direction.

When wiring, check whether thefan rotation direction is consistentwith the arrow direction.

ENERGY SAVING THCHNOLOGY

Power saving of 17000o kWh per month

The starting power of the original system is 555kw,and the starting power of the new system is 320kw.

Power saving of 17000o kWh per month

Power saving of 54000 kWh per month

The starting power of the original system is 240kW,and the starting power of the new system is 132kw.

Power saving of 54000 kWh per month

Power saving of 86000 kWh per month

The starting power of the original system is 446kW,and the starting power of the new system is 325kW.

Power saving of 86000 kWh per month

Power saving of 260000 kWh per month

The starting power of the original system is 690kw,and the starting power of the new system is 420kw.

Power saving of 260000 kWh per month

Power saving of 167000 kWh per month

The starting power of the original system is 732kW,and the starting power of the new system is 50okw.

Power saving of 167000 kWh per month

Power saving of 79000 kWh per month

The starting power of the original system is 430kw,and the starting power of the new system is 320kw.

Power saving of 79000 kWh per month
