gas tank
1.Buffers pressure fluctuations
When the compressor is running, pressure pulsations will occur, and the gas storage tank can buffer these pressure changes and keep the system pressure stable.
2.Increase system capacity
The air storage tank can store a certain amount of compressed air and provide additional air supply when the system load suddenly increases.
The gas storage tank is an important auxiliary equipment in the compressed air system. Its main functions are as follows:
Buffers pressure fluctuations
When the compressor is running, pressure pulsations will occur, and the gas storage tank can buffer these pressure changes and keep the system pressure stable.
Increase system capacity
The air storage tank can store a certain amount of compressed air and provide additional air supply when the system load suddenly increases.
Extend compressor life
The buffering effect of the gas storage tank reduces the load fluctuation of the compressor and extends its service life.
Improve system performance
The gas storage tank can improve the instantaneous gas supply capacity of the system and improve the working performance of gas equipment.
Improve system reliability
The gas storage tank can serve as a buffer and backup device for the system, improving the reliability of the entire compressed air system.
| NO | Specification Volume/pressure | Temperature | Height | Dimension | Air inlet | H2 | Air outlet | Base | Drain valve connector | Compressor Reference volume m³/min | ||||
| H1 | DN | Thread | DN | Thread | Φ1 | d | ||||||||
| 1 | 0.3/0.8 | 100.00 | 1550 | 550 | 580.00 | 50.00 | Rp1/2" | 1130 | 50 | Rp1/2" | 400.00 | 20 | R1/2" | 2.5~3 |
| 2 | 0.3/1.0 | 100.00 | 1550 | 550 | 580.00 | 50.00 | Rp1/2" | 1130 | 50 | Rp1/2" | 400.00 | 20 | R1/2" | 2.5~3 |
| 3 | 0.3/1.3 | 110.00 | 1550 | 550 | 580.00 | 50.00 | Rp1/2" | 1130 | 50 | Rp1/2" | 400.00 | 20 | R1/2" | 2.5~3 |
| 4 | 0.6/0.8 | 100.00 | 2060 | 650 | 605.00 | 65.00 | Rp1/2" | 1550 | 65 | Rp1/2" | 470.00 | 20 | R1/2" | 4.8~6 |
| 5 | 0.6/1.0 | 100.00 | 2060 | 650 | 605.00 | 65.00 | Rp1/2" | 1550 | 65 | Rp1/2" | 470.00 | 20 | R1/2" | 4.8~6 |
| 6 | 0.6/1.3 | 110.00 | 2060 | 650 | 605.00 | 65.00 | Rp1/2" | 1610 | 65 | Rp1/2" | 470.00 | 20 | R1/2" | 4.8~6 |
| 7 | 1.0/0.8 | 100.00 | 2180 | 800 | 685.00 | 65.00 | Rp1/2" | 1725 | 65 | Rp1/2" | 560.00 | 25 | R1/2" | 8~10 |
| 8 | 1.0/1.0 | 100.00 | 2180 | 800 | 685.00 | 65.00 | Rp1/2" | 1725 | 65 | Rp1/2" | 560.00 | 25 | R1/2" | 8~10 |
| 9 | 1.0/1.3 | 110.00 | 2202 | 800 | 730.00 | 65.00 | Rp1/2" | 1770 | 65 | Rp1/2" | 560.00 | 25 | R1/2" | 8~10 |
| 10 | 1.5/0.8 | 100.00 | 2290 | 1000 | 780.00 | 65.00 | Rp2" | 1780 | 65 | Rp2" | 700.00 | 24 | R1/2" | 12~15 |
| 11 | 1.5/1.0 | 110.00 | 2291 | 1000 | 780.00 | 65.00 | Rp2" | 1780 | 65 | Rp2" | 700.00 | 24 | R1/2" | 12~15 |
| 12 | 1.5/1.3 | 110.00 | 2291 | 1000 | 781.00 | 65.00 | Rp2" | 1780 | 65 | Rp2" | 700.00 | 24 | R1/2" | 12~15 |
| 13 | 2.0/0.8 | 110.00 | 2810 | 1000 | 80.00 | Rp2" | 80 | 80 | Rp2" | 700.00 | 24 | R1/2" | 16~20 | |
| 14 | 2.0/1.0 | 110.00 | 2810 | 1000 | 780.00 | 80.00 | Rp2" | 2280 | 80 | Rp2" | 700.00 | 24 | R1/2" | 16~20 |
| 15 | 2.0/1.3 | 110.00 | 2810 | 1000 | 80.00 | Rp2" | 80 | 80 | Rp2" | 700.00 | 24 | R1/2" | 16~20 | |
| 16 | 3.0/0.8 | 110.00 | 2962 | 1200 | 880.00 | 80.00 | 2380 | 80 | 840.00 | 24 | R3/4" | 24~30 | ||
| 17 | 3.0/1.0 | 110.00 | 2962 | 1200 | 881.00 | 80.00 | 2380 | 80 | 840.00 | 24 | R3/4" | 24~30 | ||
| 18 | 3.0/1.3 | 110.00 | 2964 | 1200 | 882.00 | 80.00 | 2382 | 80 | 840.00 | 24 | R3/4" | 24~30 | ||
| 19 | 4.0/0.8 | 110.00 | 3060 | 1400 | 930.00 | 100.00 | 2430 | 100 | 1050.00 | 24 | R3/4" | 32~40 | ||
| 20 | 4.0/1.0 | 110.00 | 3062 | 1400 | 931.00 | 100.00 | 2431 | 100 | 1050.00 | 24 | R3/4" | 32~40 | ||
| 21 | 4.0/1.3 | 110.00 | 3066 | 1400 | 933.00 | 100.00 | 2433 | 100 | 1050.00 | 24 | R3/4" | 32~40 | ||
| 22 | 5.0/0.8 | 110.00 | 3750 | 1400 | 930.00 | 100.00 | 3130 | 100 | 1050.00 | 24 | R3/4 | 40~50 | ||
| 23 | 5.0/1.0 | 110.00 | 3752 | 1400 | 100.00 | 3132 | 100 | 1050.00 | 24 | R3/4" | 40~50 | |||
| 24 | 5.0/1.3 | 110.00 | 3756 | 1400 | 931.00 | 100.00 | 3133 | 100 | 1050.00 | 24 | R3/4 | 40~50 | ||
| 25 | 6.0/0.8 | 110.00 | 4360 | 1400 | 930.00 | 100.00 | 3740 | 100 | 1050.00 | 24 | R3/4 | 48~60 | ||
| 26 | 6.0/1.0 | 110.00 | 4362 | 1400 | 931.00 | 100.00 | 3741 | 100 | 1050.00 | 24 | R3/4 | 48~60 | ||
| 27 | 6.0/1.3 | 110.00 | 4366 | 1400 | 932.00 | 100.00 | 3743 | 100 | 1050.00 | 24 | R3/4 | 48~60 | ||
| 28 | 8.0/0.8 | 110.00 | 4464 | 1600 | 981.00 | 150.00 | 3831 | 150 | 1200.00 | 30 | R1" | 64~80 | ||
| 29 | 8.0/1.0 | 110.00 | 4464 | 1600 | 982.00 | 150.00 | 3732 | 150 | 1200.00 | 30 | R1" | 64~80 | ||
| 30 | 8.0/1.3 | 110.00 | 4468 | 1600 | 984.00 | 150.00 | 3732 | 150 | 1200.00 | 30 | R1" | 64~80 | ||
| 31 | 10/0.8 | 110.00 | 3765 | 2000 | 1082.00 | 150.00 | 2933 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 32 | 10/1.0 | 110.00 | 3766 | 2000 | 1083.00 | 150.00 | 2933 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 33 | 10/1.3 | 110.00 | 3770 | 2000 | 1086.00 | 150.00 | 2936 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 34 | 12.5/0.8 | 110.00 | 4714 | 2000 | 1133.00 | 150.00 | 3833 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 35 | 12.5/1.0 | 110.00 | 4716 | 2000 | 1133.00 | 150.00 | 3834 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 36 | 12.5/1.3 | 110.00 | 4722 | 2000 | 1136.00 | 150.00 | 3836 | 150 | 1500.00 | 30 | R1" | 80.00 | ||
| 37 | 15/0.8 | 110.00 | 5084 | 2100 | 1172.00 | 150.00 | 4174 | 150 | 1550.00 | 30 | R1" | 80.00 | ||
| 38 | 15/1.0 | 110.00 | 5088 | 2100 | 1174.00 | 150.00 | 4175 | 150 | 1550.00 | 30 | R1" | 80.00 | ||
| 39 | 15/1.3 | 110.00 | 5094 | 2100 | 1176.00 | 150.00 | 4177 | 150 | 1550.00 | 30 | R1" | 80.00 | ||
| 40 | 20/0.8 | 110.00 | 5236 | 2400 | 1298.00 | 200.00 | 200 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 41 | 20/1.0 | 110.00 | 5240 | 2400 | 1300.00 | 200.00 | 4200 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 42 | 20/1.3 | 110.00 | 5244 | 2400 | 1302.00 | 200.00 | 200 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 43 | 25/0.8 | 110.00 | 6136 | 2400 | 1298.00 | 200.00 | 200 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 44 | 25/1.0 | 110.00 | 6140 | 2400 | 1300.00 | 200.00 | 5095 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 45 | 25/1.3 | 110.00 | 6144 | 2400 | 1302.00 | 200.00 | 200 | 200 | 1800.00 | 36 | R1" | 80.00 | ||
| 46 | 30/0.8 | 110.00 | 6896 | 2500 | 1324.00 | 200.00 | 5774 | 200 | 1900.00 | 36 | R1" | 80.00 | ||
| 47 | 30/1.0 | 110.00 | 6900 | 2500 | 1325.00 | 200.00 | 5775 | 200 | 1900.00 | 36 | R1" | 80.00 | ||
| 48 | 30/1.3 | 110.00 | 6908 | 2500 | 1329.00 | 200.00 | 5779 | 200 | 1900.00 | 36 | R1" | 80.00 | ||
| 49 | 40/0.8 | 110.00 | 8676 | 2500 | 1323.00 | 200.00 | 7603 | 1325 | 1900.00 | 36 | R1" | 80.00 | ||
| 50 | 40/1.0 | 110.00 | 8680 | 2500 | 1325.00 | 200.00 | 7600 | 1325 | 1900.00 | 36 | R1" | 80.00 | ||
| 51 | 50/0.8 | 110.00 | 9007 | 2800 | 1506.00 | 250.00 | 6750 | 250 | 3000.00 | 30 | DN40 | 80.00 | ||
| 52 | 50/1.0 | 110.00 | 9007 | 2800 | 1506.00 | 250.00 | 6750 | 250 | 3000.00 | 30 | DN40 | 80.00 | ||
| 53 | 75/1.0 | 110.00 | 10027 | 3200 | 1800.00 | 250.00 | 8200 | 250 | 3400.00 | 30 | DN40 | 80.00 | ||
| 54 | 75/0.8 | 110.00 | 10256 | 3200 | 1800.00 | 250.00 | 8200 | 250 | 3400.00 | 30 | DN40 | 80.00 | ||
AIR COMPRESSOR MAINTENANCE
01
The air compressor shouldbe placed in a place withclean air and good ventilation.
02
The air compressor should be placedhorizontally, with the belt side facingthe wall, and the maintenancespaceshould be reserved.
03
Before repairing and disassemblingthe air compressor, please tum offthe power supply and dischargethe air in the air seam.
04
When wiring, check whether thefan rotation direction is consistentwith the arrow direction.
ENERGY SAVING THCHNOLOGY
The starting power of the original system is 555kw,and the starting power of the new system is 320kw.
Power saving of 17000o kWh per month
The starting power of the original system is 240kW,and the starting power of the new system is 132kw.
Power saving of 54000 kWh per month
The starting power of the original system is 446kW,and the starting power of the new system is 325kW.
Power saving of 86000 kWh per month
The starting power of the original system is 690kw,and the starting power of the new system is 420kw.
Power saving of 260000 kWh per month
The starting power of the original system is 732kW,and the starting power of the new system is 50okw.
Power saving of 167000 kWh per month
The starting power of the original system is 430kw,and the starting power of the new system is 320kw.
Power saving of 79000 kWh per month
