◎ Yuchai diesel engine is used as the power to ensure the high reliability of the power, long operating life, good fuel economy, suitable for harsh working conditions in the field.
◎ High efficiency, energy saving, stable and reliable; Easy to operate, operation at a glance.
◎ The reasonable matching design of fan and cooler ensures the normal operation of the fan and cooler.
◎ Yuchai diesel engine is used as the power to ensure the high reliability of the power, long operating life, good fuel economy, suitable for harsh working conditions in the field.
◎ High efficiency, energy saving, stable and reliable; Easy to operate, operation at a glance.
◎ The reasonable matching design of fan and cooler ensures the normal operation of the fan and cooler.
◎ Stepless air intake control, high efficiency and energy saving
◎ High efficiency four-stage motor, longer service life, more reliable
◎ Reasonable chassis design, making the fuselage more solid and stable.
Innovate technology to protect the environment.Kapa listens, understands and meets the needs of customers.Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution. With the mission of "innovation embodies value", Kapa Company will continue to promote technological innovation and progress, achieve win-win with global partners, suppliers and employees, create a new world of "energy saving, environmental protection, intelligence and service" in the aerodynamic field, and strive to be a world-class enterprise with world-class standards.
1. High quality control(CE, SGS, ISO14001/Energy saving certificate)
2. Fast Delivery( 25-30 days for large orders)
3. Good service for pre-sale, after-sale( strong technical support and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your actual needs)
Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.
KPMDVS series (single stage)
Model | Nominal Power | Working Pressure | Free Air Delivery | Weight(KG) | Noise Level | Dimensions (LxWxH) | Outlet size | |||||
KW | HP | bar | psi | m3/min | cfm | KG | db(A) | (mm) | ||||
KPMDVS30-8 | 30 | 40 | 8 | 116 | 5.0 | 176.57 | 485 | / | 1620 | 860 | 1100 | G1+G1-1/2 |
KPMDVS90-14.5 | 90 | 125 | 14.5 | 210 | 13.00 | 459.09 | 1800 | / | 2550 | 1400 | 1800 | G1+G1-1/2 |
KPMDVS110-8 | 110 | 150 | 8 | 116 | 20.00 | 706.29 | 2500 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS132-8 | 132 | 175 | 8 | 116 | 24.0 | 847.55 | 2600 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS132-17 | 132 | 175 | 17 | 247 | 15.0 | 529.72 | 2480 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS185-13 | 185 | 250 | 13 | 189 | 26.0 | 918.18 | 3500 | / | 3500 | 1950 | 2650 | G1+G2 |
Model | Nominal Power | Working Pressure | Free Air Delivery | Weight(KG) | Noise Level | Dimensions (LxWxH) | Outlet size | |||||
KW | HP | bar | psi | m3/min | cfm | KG | db(A) | (mm) | ||||
KPMDVS90-13.8Ⅱ | 90 | 120 | 13.8 | 200 | 18.0 | 635.66 | 2690 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS90-14.5Ⅱ | 90 | 120 | 14.5 | 210 | 18.0 | 635.66 | 2690 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS90-15Ⅱ | 90 | 120 | 15.0 | 218 | 17.0 | 600.35 | 2690 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS132-18Ⅱ | 132 | 175 | 18 | 261 | 21.0 | 741.61 | 2700 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS138-18Ⅱ | 132 | 175 | 18 | 261 | 23.0 | 812.24 | 2800 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS138-19Ⅱ | 132 | 175 | 19 | 276 | 22.0 | 776.92 | 2800 | / | 3100 | 1700 | 2050 | G1+G2 |
KPMDVS185-24Ⅱ | 185 | 250 | 24 | 348 | 23.0 | 812.24 | 3300 | / | 3500 | 1950 | 2650 | G1+G2 |
KPMDVS185-18Ⅱ | 185 | 250 | 18 | 261 | 28.0 | 988.81 | 3300 | / | 3500 | 1950 | 2650 | G1+G2 |
KPMDVS200-20Ⅱ | 200 | 275 | 20 | 290 | 26.0 | 918.18 | 3400 | / | 3500 | 1950 | 2650 | G1+G2 |
KPMDVS250-20Ⅱ | 250 | 350 | 20 | 290 | 30.0 | 1059.44 | 4000 | / | 3500 | 1950 | 2650 | G1+G2 |
AIR COMPRESSOR MAINTENANCE
01
The air compressor shouldbe placed in a place withclean air and good ventilation.
02
The air compressor should be placedhorizontally, with the belt side facingthe wall, and the maintenancespaceshould be reserved.
03
Before repairing and disassemblingthe air compressor, please tum offthe power supply and dischargethe air in the air seam.
04
When wiring, check whether thefan rotation direction is consistentwith the arrow direction.
ENERGY SAVING THCHNOLOGY
The starting power of the original system is 555kw,and the starting power of the new system is 320kw.
Power saving of 17000o kWh per month
The starting power of the original system is 240kW,and the starting power of the new system is 132kw.
Power saving of 54000 kWh per month
The starting power of the original system is 446kW,and the starting power of the new system is 325kW.
Power saving of 86000 kWh per month
The starting power of the original system is 690kw,and the starting power of the new system is 420kw.
Power saving of 260000 kWh per month
The starting power of the original system is 732kW,and the starting power of the new system is 50okw.
Power saving of 167000 kWh per month
The starting power of the original system is 430kw,and the starting power of the new system is 320kw.
Power saving of 79000 kWh per month
